Welcome! The Commander X16 is David Murray aka The 8-Bit Guy’s dream computer, designed to evoke the same fondness and nostalgia many of us had for 8-Bit computers, whilst retaining closeness to the hardware from a programming perspective, unlike the Raspberry Pi and others. But more than that, it is intended not only as an educational tool but to solve some of the issues of finding an 8-Bit system to tinker with today; namely ever-increasing costs, auction site price gouging/sniping, lack of replacement parts, and unreliability of 30-year old hardware.

The X16 will be made entirely with parts that are still readily available today, ensuring perpetual availability without reliability issues, but in keeping with David's vision, it will house a real CPU rather than using emulation or an FPGA recreation of a processor. Running Commodore BASIC V2 (with some additions), the X16 will be inexpensive enough to allow a critical mass of users to create an expansive software ecosystem, but simple enough that a single person can understand all of the chips and components that allow that software to run.

Three phases of the computer are planned under the "Commander X16" brand umbrella, each phase decreasing in size and cost. Please see David's 2nd video below for information on the phases.



Please watch David's Commander X16 video playlist for further details, starting with Part 1:



Commander X16P Features & Specifications (subject to change)

• CPU
  • WDC 65C02S @ 8 MHz
  • 40-pin DIP package
  • Protoype board currently running stable at 8 MHz
• RAM
  • 40K of "Low RAM":
    • As 39.75K + 256 bytes of IO space
    • 8 IO spaces of 32 bytes each; one for the VERA, one for the VIAs, one for the audio
  • 512K of "High RAM" standard:
    • As 64 banks of 8K
  • Expandable to 1 MB, 1.5 MB, or 2 MB by adding additional RAM chips to 3 empty sockets
    • Up to 256 banks of 8K
• ROM
  • 512K of Flash ROM
    • As 32 banks of 16K (TBD: Could be expanded to 128 banks RAM or ROM)
  • Standard Commodore Kernal
  • Microsoft BASIC version 2.0
  • Machine Language Monitor
  • TBD: May be able to be flashed from the X16
• Expansion
  • Four expansion slots with access to CPU databus
  • Each slot has its own 32-bytes of mapped RAM
  • Each slot can select from one or more of 5 addressable 32 bytes of IO space
  • 13 general-purpose I/O lines available (user port)
• Input Devices
  • PS/2 Keyboard
  • PS/2 Mouse
  • Two SNES style game ports (two more as pin headers)
• Storage
  • IEC compatible (Commodore) disk drive port
  • Internal SD card slot on VERA
• Audio
  • There are 2 designs in final testing and one or both will remain:
    • Yamaha YM2151 sound chip
    • SID-like implementation in the VERA FPGA chip
    • (SAA1099 has been retired)
• "VERA" module specifications
  • Video generator featuring:
    • Multiple output formats (VGA, NTSC Composite, NTSC S-Video, RGB video) at a fixed resolution of 640x480@60Hz
    • Support for 2 layers, both supporting:
      • 1/2/4/8 bpp tile and bitmap modes
      • Support for up to 128 sprites (with inter-sprite collision detection).
    • Embedded video RAM of 128 KB.
    • Palette with 256 colors selected from a total range of 4096 colors.
  • 16-channel stereo Programmable Sound Generator with multiple waveforms (Pulse, Sawtooth, Triangle, Noise)
  • High quality PCM audio playback from an 4 KB FIFO buffer featuring up to 48kHz 16-bit stereo sound.
  • SecureDigital storage.
• Board power consumption: ~15W
• PSU: TBC

There is no firm release date or price set for Phase 1 yet. Phases 2 & 3 (X16C, X16E) will follow on, with different specs and price.

The issues with the Coronavirus and chip shortages are delaying aspects of the product that depend on China. The full impact to the project remains to be seen. As of December 2021 David has suggested there could be a "9 to 12 month" delay.

Meanwhile development, testing, and bug fixing of the prototypes continue. Ultimately, “It’ll be ready when it’s ready” :-) Once we have a viable prototype, we will announce the crowdfunding, which is likely to take place at this website. Please look out for updates, and kindly do not ask for pricing, release date updates, or update videos as these requests put unnecessary pressure on David and the team. Thank you.

How much will it cost?

Pricing has not been announced yet. The goal is to make the most affordable modern retro computer possible. The hope is still that Phase 3 (the X16E) will be available well under $100 as indicated in David's first video.

This entire computer is meant to be a close relative of the Commodore systems. While technically Commodore BASIC is actually Microsoft BASIC, David wants it to be as similar as possible to programming on a VIC-20, C64, or Plus/4. It will run BASIC v2 with some additions. We have reached agreement with the rights holder to license it for this purpose.

There’s no reason you couldn’t program in C++ or whatever on this computer if somebody wants to port over a compiler. Alternatively, you can use a cross-compiler like cc65.

Will it be compatible with Commodore 64 software?

Why the name "X16"?

"Commander 16" would be abbreviated to "C16" and too easily confused with the Commodore "C16", so when Perifractic proposed the always cool "X" be added to make "X16" it got the team's vote. As for "16" the original design was to use an 816 processor, however the machine still has a 16-bit address space. But above all, the X16 is an 8-bit machine with 16-bit tendencies. Commander X16!

VGA is fairly easy to implement as compared to HDMI. And worst case, there are low-cost chips that can convert VGA to HDMI. And if you have to convert to HDMI, far better to convert from VGA than from composite.

There will be up to 4 expansion slots that could be used for just about anything. One drawback of running at 8 MHz will be that many chips like SID chips will not run that fast, so additional logic would have to be implemented on the card in order to communicate with the chip.

SNES style game controllers. There are a few reasons for this:

At the moment we need software development. The emulator is now available and people can start writing their own code. You can upload your creations to the software library at this website.

We haven't decided for certain. The problem with selling it as a kit is that the design team will not have time for being end-user tech support. So, while the kit may end up being cheaper, it will also be sold without official technical support - although this website has been set up so people can still obtain support from the community and/or developers. If people assemble it and it doesn’t work, they can ask for support there. We will update the FAQ once a decision has been reached about whether to provide a kit option. As for a motherboard only option, our focus now is on releasing the computer. Once the project is launched and established, we will revisit these kind of options.

Perifractic (who also designed this website) designed a bespoke PETSCII mini keyboard that will be included with all X16 orders. The prototype is now in hand and the deposit for the first 1000 units has been paid.

By popular demand from keyboard connoisseurs there is also a premium microswitch keyboard option available from WASD available now and compatible with the emulator and X16 itself.

Why PS/2 Keyboard and not USB?

Updated answer here written by Perifractic:

Why is the keyboard separate not integrated into a case like a C64?

There are a few reasons:

• The Phase 1 motherboard is likely too large to fit inside a keyboard-case, and doing so would also rule out having full height internal expansion cards like an Apple ][.
• We have heard comments like "retro computers are all-in-one with integrated keyboard!"... then again there was the Amiga 1000, A2000, A2500, A3000, A4000, Apple Macintosh, Apple III, Apple IIGS, Commodore 128D, Amstrad PCW, Amstrad PC1512, Amstrad PC1640, Acorn Archimedes, Sony MSX, Atari Mega ST, Atari TT030, Coleco Adam, & many more beautiful retro machines with separate keyboards.
• We and many users believe that the flexibility of being able to position the main computer away from the keyboard on your desk, without multiple wires trailing across the desk between, is actually a functional bonus and why Apple went this route with the Macintosh, with the others following suit.
• We also aren't going with 3D printing due to speed, cost, & quality concerns. The technology just isn’t ready yet.

What about expansion cards for each phase?

Why isn't a monitor included?

Perifractic designed a nostalgic traditional spiral bound Getting Started guide with an awesome (top secret) cover co-created by him and Trevor Storey. The manual includes a BASIC programming guide. The rest of the team are currently finishing up the finer details of the manual. Further docs are already available in the Downloads section of this website. The working title for the spiral bound guide is “Just the BASICs: Getting started with the Commander X16”. There will also be “Assembling Assembly” and a programmer’s reference guide. PDFs will likely be an option.

We will not be using the Propeller for these reasons:

We are exploring this option. An ideal GUI might use a text character set, rather than graphics - see http://www.c64os.com/c64os as a reference. The emulator also already incorporates GEOS. Type "GEOS" to get started, although it is still in beta and you will need a GEOS disk image file to get started.

Yes, you can download it from via the Downloads section of this site or try the web-based emulator from the home page!

Yes, just click Downloads above to get started!

What is the correct short-name for the Commander X16?

At some point, most likely yes. However we have to consider that part of the code that makes the whole system work is owned by other rights holders who inherited it from Commodore/Microsoft and whom we have licensed it from (only some parts of the emulator are covered by the BSD-2 Clause License, not all parts). Before making the entire X16 open source or allowing custom machine builds based around our code, we will need to get the necessary additional permissions or work out a way that is acceptable to all parties. This will happen some time after the machine's physical releases. Until then, we cannot encourage clone machines based on the X16 code as it may jeopardize the license relationships we worked hard to forge. Thanks for your understanding.

Will there be a beta programme?

Is this a commercial or not-for-profit venture?

The Commander X16 has been developed by a team of enthusiasts who shared David's vision to create a reliable, low cost, modern retro computer for the benefit of the retro community. The team is committed to launching the Commander X16 at the lowest price possible while still ensuring that the team will be reimbursed for out of pocket expenses incurred during the 2+ year development process (such as parts, prototypes, shipping, web hosting, etc.) David and the team are not looking to profit from the project and instead seek to strike a balance between continuing to produce the Commander X16 at an affordable price while also meeting the ongoing costs associated with continued development, manufacture, and infrastructure (e.g., website hosting, legal assistance, prototyping, deposits on parts, and so on).

The team has included at various points:
